VJ2380

Tag: Coding Printers, High Resolution, Large Character, LCM, Videojet

A versatile solution that adapts to your requirements

Two printheads can be easily integrated, with no additional hardware needed, allowing coding of up to 5.5 inch (140mm) high print spaces, or coding on two sides of a box
The system offers USB, VideojetConnect™, and ZPL emulation
A bar code scanner can be easily integrated with the HMI for rapid job selection and data entry
Wi-Fi connectivity is embedded in the printer, for remote access and analytical capabilities

Consistent, reliable high-quality codes

A patented, automated micro-purge system can be programmed to clean the printhead nozzles at specific intervals, helping to prevent blockages without stopping the production line
An air knife helps to clean the printhead nozzle plate, supporting long production runs
A gyroscopic sensor monitors the printer mounting angle in real-time, helping to prevent ink leaks, and detects and records external impact signals

An easy-to-use marking system

An intuitive, easy-to-use touchscreen HMI offers code assurance and guides you every step of the way, greatly reducing printer interactions and potential user errors
The touchscreen user interface offers onboard job editing, can be placed in an optimal position for the operator, and manages up to two printheads
Existing CLARiTY™ print jobs are 100% compatible with the Videojet 2380 and can be downloaded via USB, for easy upgrading
A low-cost return line filter changes the associated ink-cup cleaning cycle from daily to monthly, reducing maintenance, while wiping the printhead surface is the only daily maintenance recommended

Expertly designed for the way you work

The Videojet 2380 is made of durable 304-grade stainless steel
Ink used in the micro-purge printhead cleaning system is reclaimed and reused by the printer, reducing running costs
A contrast adjuster allows the contrast density to be reduced, enabling more prints per ink canister
The robust printhead uses proven print technology to deliver optimal uptime

All industries. Corrugated: direct marking

Specification	Value
Print Speed
Bar Code Printing	0.3 – 66 m/min (1.0 – 216 ft/min)
Alphanumeric Text	Up to 132 m/min (433 ft/min)
Alphanumeric Text	Speeds are density dependent
Print Area (Height x Length)	70 x 2000 mm (2.8 x 78 in)
Printheads	70 mm (2.8 in) high 180 dpi
User Interface	8″ high-response TFT-LCD touch screen
Connectivity options	RS232, dual Ethernet and Wi-Fi
On-Board Memory	8 GB memory

Regional after-sales support.
